Ultra Insulated Panel Systems Inc
- UPR -250 Roof Panel
- UPW Wall Panel
- UCSP Cold Storage Panel
- UPI Insulation Board
- FUSE Building System
Specification
| Effective Coverage | : | 1000 mm |
| Rib Height | : | 33 mm |
| Rib Spacing | : | 250 mm |
| Insulation Thickness | : | 25, 50, 75 and 100 mm |
| Insulation Material | : | POLYISOCYANURATE (PIR) / POLYURETHANE (PU) |
| Density | : | 35-40 kg/m3 |
| Material Finish | : | Colorlume, Galvalume, PVDF |
| Aluminum and Stainless | ||
| Metal Thickness | : | From 0.40 mm to 0.60mm (standard) *a specific tonnage is required for non-standard thickness |
| Length of Panel | : | Up to transportable length (depends on the location) |
Specification
| Effective Coverage | : | 1000 mm |
| Rib Height | : | 2 mm / 5 mm |
| Rib Spacing | : | 250 mm / 500 mm |
| Insulation Thickness | : | 50, 75 and 100 mm |
| Insulation Material | : | POLYISOCYANURATE (PIR) / POLYURETHANE (PU) |
| Density | : | 35-40 kg/m3 |
| Material Finish | : | PPGI, Galvalume, PVDF |
| Aluminum and Stainless | ||
| Metal Thickness | : | From 0.40 mm to 0.60mm (standard) *a minimum tonnage is required for non-standard thickness |
| Length of Panel | : | Up to transportable length (depends on the location) |
Specification
| Effective Coverage | : | 1150 mm |
| Rib Height | : | 2 mm |
| Insulation Thickness | : | 25, 50, 75 and 100 mm |
| Insulation Material | : | POLYISOCYANURATE (PIR) / POLYURETHANE (PU) |
| Density | : | 32-35 kg/m3 or depends on your density requirement3 |
| Material Finish | : | Colorlume, Galvalume |
| Aluminum and Stainless | ||
| Metal Thickness | : | From 0.40 mm to 0.60mm (standard) *a specific tonnage is required for non-standard thickness |
| Length of Panel | : | Up to transportable length (depends on the location) |
Specification
| Effective Coverage | : | 1150 mm |
| Rib Height | : | 2 mm |
| Insulation Thickness | : | 25, 50, 75 and 100 mm |
| Insulation Material | : | POLYISOCYANURATE (PIR) / POLYURETHANE (PU) |
| Density | : | 32-35 kg/m3 or depends on your density requirement3 |
| Material Finish | : | Colorlume, Galvalume |
| Aluminum and Stainless | ||
| Metal Thickness | : | From 0.40 mm to 0.60mm (standard) *a specific tonnage is required for non-standard thickness |
| Length of Panel | : | Up to transportable length (depends on the location) |
